Machine |
Description |
Specification |
No of Unit |
To Validate |
 |
Shear Test Machine |
Max 40,000lbs |
1 |
Pressure (psi)for Shear Screws |
 |
Mitutoyo CMM
CRYSTA-APEX S7106 |
X=700MM
Y=1000MM
Z=600MM |
1 |
Precise Measurement |
 |
Image Dimension
Measurement System-IM-6120 |
X=100MM / Z=30MM |
1 |
Dimension
Angle
Diameter |
 |
Clark Hardness Tester |
HRA,HRB & HRC |
1 |
Material/Product
Hardness (HRB & HRC) |
 |
King Brinell Hardness Tester |
HRB |
1 |
Raw Material Hardness |
 |
Mic Track |
IT 6000 & PD 8001 |
1 |
OD & ID Pitch Diameter |
 |
Roughness Tester |
X= 1" |
1 |
Surface Finishing Roughness,Waviness,etc |
 |
Rec Profile Projector |
X=200mm
Y=100mm |
1 |
Dimensions
Angle
Radius |
 |
Thread Comparator
(Ptich Diameter Size & Functional Size) |
01.190" -1.000" |
1 |
Thread Conditions & Ptich Diameter |
.jpg) |
Pitch Diameter |
Thread Size |
3 |
Thread Size |
 |
Mitutoyo Height gage
HDM-24"AX |
Max 24" |
1 |
Height Distance |
 |
Tri Roll Thread Gage |
0.375" & 0.5" |
1 |
Thread Conditions |
 |
OD Micrometer |
0 - 12" |
1 |
OD Diameter |
 |
Ring Gages |
Various Sizes |
1 |
OD Threads |
 |
Plug Gage |
Various Sizes |
1 |
ID Threads |
 |
STUD ACME Comb Gage |
Various Sizes |
1 |
Stud Acme Thread Pitch |
 |
FORMTRACER
Model: C-3200
|
X = 100 mm
Z = 700 mm
|
1
|
Form surface measurement
|
 |
OASIS
measurement machine
Model:
Elite & CORE X2
|
Measurement Scale:
1) Elite: 1” x 1”
2) CORE X2: 3.30” X
2.70”
Accuracy: +/-0.0001”
|
1
|
Instant measurement |
|
|
DIGIMAR Digital Height gauge
Model: 816 CL
|
Measurement length: 600mm
Accuracy: 0.00004”
|
1
|
Height measurement dimension |
|
|
Mitutoyo CMM
Model:
CRYSTA-APEX S9106
|
X = 900 mm
Y = 1000 mm
Z = 600 mm
|
1
|
Precision measurement |
|
|
TEST RESOURCESS
Compression test machine (Shear test)
Model:
326 (300kN) & 326 (500kN)
|
Max load:
1) 300kN (67500 lbf)
2) 500kN (112,404 lbf)
|
2
|
Shear test |
|
|
CLARK CPT
Portable Hardness tester
Model:
CPT & CPT XL
|
Maximum diameter testing:
1) CPT: Up to 4”
2) CPTXL: Up to 12”
|
2
|
Hardness value |
 |
MITUTOYO
Model:
Roundness RA-2200AH
|
Measurement Scale:
Radial Accuracy = ± 0.02 µm
Vertical Accuracy = ± (0.1 + 0.0001L) µm
L=measured height in mm
|
1 |
Precision measurement
(Roundness, Cylindricity, Flatness
and Straightness) |
